Waterproof Column Timber Formwork 200x80mm Formwork For Slab And Wall Shuttering System

Brand Name : WKS

Certification : ROHS

Place of Origin : Hebei,China

MOQ : 50 piece

Price : US $5.90 - 6.80/ Square Meter

Payment Terms : T/T

Supply Ability : 1000 piece in 10 days

Delivery Time : 10-30 workday

Packaging Details : Bundled / Tied in bundles/Optimization of container loading

Product name : Column Timber Formwork

Wood type : Finland Spruce/fir&plywood

Material : Flange :spruce/fir wood , Web:poplar plywood

Bending Bearing Moment : 11KN M

Shear Capacity (broken loading) : 24KN

web thickness : 27mm or 30mm

Color : yellow

Width : 8cm

Height : 20cm

Length : 900mm-5900mm

Contact Now

H20 Timber Beam Formwork 200x80mm for Slab and Wall Shuttering System
Product Overview

The H20 Timber Beam is an engineered wood I-beam system designed as the primary support structure for slab, wall, and column formwork. Combining solid timber flanges with a plywood web, it delivers a high strength-to-weight ratio for efficient concrete shaping in commercial and civil projects.

Features & Functions
  • Lightweight & Manual Handling: At only ~4.8-5.0 kg/m, a single worker can easily carry and position beams, eliminating the need for crane assistance in many setups and speeding up assembly.
  • Long Span Capability: The "H20" classification (200mm height) provides high bending resistance, allowing wider spacing between support props (typically 1.0-1.5m for slabs), which clears site access and reduces material count.
  • Nail-able & Customizable: Unlike metal beams, the timber flanges can be easily nailed or screwed on-site, allowing for simple attachment of plywood sheathing and quick modifications to fit complex layouts.
  • Water-Resistant Construction: Treated with waterproof glue and anti-corrosion coatings, the beams withstand harsh site conditions and moisture exposure, ensuring dimensional stability during concrete curing.
Key Specifications
  • Standard Size: 80mm (W) x 200mm (H)
  • Flange Material: Solid Spruce/Pine/Fir (KD)
  • Web Material: 10-12mm Birch/Hardwood Plywood
  • Common Lengths: 1.5m - 6.0m (customizable)
  • Adhesive: Phenolic (WBP) waterproof glue
  • Max Reuse: 20-50 cycles (with proper care)
Technical Specifications
Product H20 Timber Beam
Wood Type Finland Spruce/Fir & Plywood
Color Yellow
Width 8cm
Height 20cm
Length 900mm - 5900mm
Weight Approximately 4.5kg - 30kg
Materials Flange: Spruce/Fir Wood, Web: Poplar Plywood
Wood Moisture 12% ± 3% at delivery
Surface Protection Waterproofed using water-repellent color glaze
Flange Wall Width: 80mm, Thickness: 40mm
Web Thickness 27mm or 30mm
Shear Capacity 24KN (broken loading)
Bending Bearing Moment 11KN*M
Application Scope

Residential & commercial buildings, concrete tanks, basements, bridge abutments and piers, irregular concrete structures, and various engineering projects including buildings, water conservancy, hydropower, bridges, culverts, and high-rise structures.

Waterproof Column Timber Formwork 200x80mm Formwork For Slab And Wall Shuttering System
Competitive Advantages
Cost-Effective Support Solution: Offers a significantly lower initial investment compared to full aluminum or steel frame systems, while providing sufficient strength for most standard concrete pours.
System Compatibility: Designed to work seamlessly with major international formwork systems (Doka, PERI, etc.) and standard plywood panels, making it a versatile choice for contractors.
Reduced Prop Density: The high load capacity reduces the number of vertical supports required, lowering rental costs and creating a less cluttered, safer working environment.
Experienced Engineering Team: Average working experience of 10+ years ensuring professional solutions.
Production Excellence: Over 20 years of production experience ensuring stable product quality.
Cost Advantages: Factory located in industrial cluster area providing significant cost benefits.
Full Cycle Services: Comprehensive project services to ensure smooth application of H20 timber beam formwork.
One-Stop Solution Service Process
Free Consultation Service: Provide construction drawings for evaluation of cost-effective formwork system solutions with detailed quotation.
Full Process Project Team Service: Dedicated team for professional engineering solutions, business communication, and on-site construction management.
Project Emergency Plan Service: Comprehensive planning including emergency handling procedures for formwork system products.
Frequently Asked Questions
Are you a trading company or a manufacturer?
We are a subsidiary foreign trade company of a group company, responsible for exporting formwork and scaffolding products. Our group has two major production bases with over 20 years of production experience.
What services do you provide?
We provide professional implementation solutions, high-quality products, and efficient technical support services in the field of templates and scaffolding.
Do you provide samples? Are samples chargeable?
Yes, we provide samples. Customers pay for shipping costs.
What information is needed for design and quotation?
Architectural and structural drawings of the project are required.
How to get a quotation?
For simple projects with your own engineer, provide bill of materials. For complex projects like apartments and residences, provide engineering drawings for our engineers to develop application plans and quotations.
How long for design and quotation after providing drawings?
Typically 5-8 days to complete specific plans and detailed quotations.
What is the delivery time after contract signing?
Usually 20-30 days for stocking, depending on project complexity. More accurate timelines provided during planning.
What are your payment terms?
T/T: 30% deposit before manufacture, 70% balance against B/L copy. Or L/C.
